CPE structure for CPE PHY. More...

#include <802_22.h>

Collaboration diagram for stru_802_22_CPE_PHY:

Data Fields
double	T20
	Time the CPE searches for preambles on a given channel. More...

int	nBWRequestBackoffStart
	Initial size of BW Request opportunity used by CPEs to contend to send BW requests to BS. Range 0-15. More...

int	nBWRequestBackoffEnd
	Final size of BW Request opportunity used by CPEs to contend to send BW requests to BS. Range 1-15. More...

SYMBOL_PARAMETER *	pstruSymbol
	Same parameter as BS have. More...

unsigned int	nIntraFrameQuietPeriodLength

char	szIntraFrameQuietPeriodBitmap [17]

unsigned int	nIntraFrameQuietPeriodDuration

unsigned int	nFrameNumber

double	dTXPower

double	dAntennaHeight

double	dAntennaGain

struct stru_802_22_Channel *	pstruOperatingChannel

struct stru_802_22_Channel *	pstruChannelSet

Detailed Description

CPE structure for CPE PHY.

Definition at line 901 of file 802_22.h.

Field Documentation

◆ dAntennaGain

double stru_802_22_CPE_PHY::dAntennaGain

Definition at line 917 of file 802_22.h.

◆ dAntennaHeight

double stru_802_22_CPE_PHY::dAntennaHeight

Definition at line 916 of file 802_22.h.

◆ dTXPower

double stru_802_22_CPE_PHY::dTXPower

Definition at line 915 of file 802_22.h.

◆ nBWRequestBackoffEnd

int stru_802_22_CPE_PHY::nBWRequestBackoffEnd

Final size of BW Request opportunity used by CPEs to contend to send BW requests to BS. Range 1-15.

Definition at line 908 of file 802_22.h.

◆ nBWRequestBackoffStart

int stru_802_22_CPE_PHY::nBWRequestBackoffStart

Initial size of BW Request opportunity used by CPEs to contend to send BW requests to BS. Range 0-15.

Definition at line 906 of file 802_22.h.

◆ nFrameNumber

unsigned int stru_802_22_CPE_PHY::nFrameNumber

Definition at line 914 of file 802_22.h.

◆ nIntraFrameQuietPeriodDuration

unsigned int stru_802_22_CPE_PHY::nIntraFrameQuietPeriodDuration

Definition at line 913 of file 802_22.h.

◆ nIntraFrameQuietPeriodLength

unsigned int stru_802_22_CPE_PHY::nIntraFrameQuietPeriodLength

Definition at line 911 of file 802_22.h.

◆ pstruChannelSet

struct stru_802_22_Channel* stru_802_22_CPE_PHY::pstruChannelSet

Definition at line 919 of file 802_22.h.

◆ pstruOperatingChannel

struct stru_802_22_Channel* stru_802_22_CPE_PHY::pstruOperatingChannel

Definition at line 918 of file 802_22.h.

◆ pstruSymbol

SYMBOL_PARAMETER* stru_802_22_CPE_PHY::pstruSymbol

Same parameter as BS have.

Definition at line 910 of file 802_22.h.

◆ szIntraFrameQuietPeriodBitmap

char stru_802_22_CPE_PHY::szIntraFrameQuietPeriodBitmap[17]

Definition at line 912 of file 802_22.h.

◆ T20

double stru_802_22_CPE_PHY::T20

Time the CPE searches for preambles on a given channel.

Definition at line 904 of file 802_22.h.

The documentation for this struct was generated from the following file:

802_22.h
