P2P.c File Reference

#include "main.h"
#include "P2P.h"
#include "P2P_Enum.h"

Include dependency graph for P2P.c:

Go to the source code of this file.

Functions
static void	add_event_link_up ()
static int	fn_NetSim_P2P_CalulateReceivedPower ()
int	P2P_MacOut_Handler ()
int	P2P_MacIn_Handler ()
int	P2P_PhyOut_Handler ()
int	P2P_PhyIn_Handler ()
int	fn_NetSim_P2P_Run ()
PHY_MODULATION	getModulationFromString (char *val)
static void	configure_wireless_P2P (NETSIM_ID d, NETSIM_ID in, void *xmlNetSimNode)
int	fn_NetSim_P2P_Configure (void **var)
int	fn_NetSim_P2P_Init (struct stru_NetSim_Network *NETWORK_Formal, NetSim_EVENTDETAILS *pstruEventDetails_Formal, char *pszAppPath_Formal, char *pszWritePath_Formal, int nVersion_Type, void **fnPointer)
int	fn_NetSim_P2P_Finish ()
char *	fn_NetSim_P2P_Trace (int nSubEvent)
int	fn_NetSim_P2P_FreePacket (NetSim_PACKET *pstruPacket)
int	fn_NetSim_P2P_CopyPacket (NetSim_PACKET *pstruDestPacket, NetSim_PACKET *pstruSrcPacket)
int	fn_NetSim_P2P_Metrics (PMETRICSWRITER metricsWriter)
char *	fn_NetSim_P2P_ConfigPacketTrace (const void *xmlNetSimNode)
int	fn_NetSim_P2P_WritePacketTrace (NetSim_PACKET *pstruPacket, char **ppszTrace)
static void	p2p_gettxinfo (NETSIM_ID nTxId, NETSIM_ID nTxInterface, NETSIM_ID nRxId, NETSIM_ID nRxInterface, PTX_INFO Txinfo)
static bool	CheckFrequencyInterfrence (double dFrequency1, double dFrequency2, double bandwidth)
static bool	check_interference (NETSIM_ID t, NETSIM_ID ti, NETSIM_ID r, NETSIM_ID ri)
static int	p2p_CalculateReceivedPower (NETSIM_ID tx, NETSIM_ID txi, NETSIM_ID rx, NETSIM_ID rxi)
int	fn_NetSim_P2P_LinkStateChanged (NETSIM_ID linkId, LINK_STATE newState)

Function Documentation

add_event_link_up()

static void add_event_link_up ( )

static

Definition at line 399 of file P2P.c.

Here is the call graph for this function:

Here is the caller graph for this function:

check_interference()

static bool check_interference ( NETSIM_ID  t, NETSIM_ID  ti, NETSIM_ID  r, NETSIM_ID  ri  )

static

Definition at line 307 of file P2P.c.

Here is the call graph for this function:

Here is the caller graph for this function:

CheckFrequencyInterfrence()

static bool CheckFrequencyInterfrence ( double  dFrequency1, double  dFrequency2, double  bandwidth  )

static

Definition at line 289 of file P2P.c.

Here is the caller graph for this function:

configure_wireless_P2P()

static void configure_wireless_P2P ( NETSIM_ID  d, NETSIM_ID  in, void *  xmlNetSimNode  )

static

Definition at line 93 of file P2P.c.

Here is the call graph for this function:

Here is the caller graph for this function:

fn_NetSim_P2P_CalulateReceivedPower()

static int fn_NetSim_P2P_CalulateReceivedPower ( )

static

Definition at line 325 of file P2P.c.

Here is the call graph for this function:

Here is the caller graph for this function:

fn_NetSim_P2P_ConfigPacketTrace()

char * fn_NetSim_P2P_ConfigPacketTrace

(

const void *

xmlNetSimNode

)

This function will return the string to write packet trace heading.

Definition at line 256 of file P2P.c.

fn_NetSim_P2P_Configure()

int fn_NetSim_P2P_Configure

(

void **

var

)

This function is called by NetworkStack.dll, while configuring the device Mac/Phy layer for P2P protocol.

Definition at line 128 of file P2P.c.

Here is the call graph for this function:

fn_NetSim_P2P_CopyPacket()

int fn_NetSim_P2P_CopyPacket	(	NetSim_PACKET *	pstruDestPacket,
		NetSim_PACKET *	pstruSrcPacket
	)

This function is called by NetworkStack.dll, to copy the P2P protocol from source packet to destination.

Definition at line 240 of file P2P.c.

fn_NetSim_P2P_Finish()

int fn_NetSim_P2P_Finish

(

)

This function is called by NetworkStack.dll, once simulation end to free the allocated memory for the network.

Definition at line 200 of file P2P.c.

fn_NetSim_P2P_FreePacket()

int fn_NetSim_P2P_FreePacket

(

NetSim_PACKET *

pstruPacket

)

This function is called by NetworkStack.dll, to free the P2P protocol

Definition at line 232 of file P2P.c.

fn_NetSim_P2P_Init()

int fn_NetSim_P2P_Init	(	struct stru_NetSim_Network *	NETWORK_Formal,
		NetSim_EVENTDETAILS *	pstruEventDetails_Formal,
		char *	pszAppPath_Formal,
		char *	pszWritePath_Formal,
		int	nVersion_Type,
		void **	fnPointer
	)

This function initializes the P2P parameters.

Definition at line 184 of file P2P.c.

Here is the call graph for this function:

fn_NetSim_P2P_LinkStateChanged()

int fn_NetSim_P2P_LinkStateChanged	(	NETSIM_ID	linkId,
		LINK_STATE	newState
	)

Definition at line 356 of file P2P.c.

Here is the caller graph for this function:

fn_NetSim_P2P_Metrics()

int fn_NetSim_P2P_Metrics

(

PMETRICSWRITER

metricsWriter

)

This function write the Metrics in Metrics.txt

Definition at line 248 of file P2P.c.

fn_NetSim_P2P_Run()

int fn_NetSim_P2P_Run

(

)

This function is called by NetworkStack.dll, whenever the event gets triggered inside the NetworkStack.dll for the Mac/Phy layer P2P protocol It includes MAC_OUT, MAC_IN, PHY_OUT, PHY_IN and TIMER_EVENT.

Definition at line 41 of file P2P.c.

Here is the call graph for this function:

fn_NetSim_P2P_Trace()

char * fn_NetSim_P2P_Trace

(

int

nSubEvent

)

This function is called by NetworkStack.dll, while writing the event trace to get the sub event as a string.

Definition at line 224 of file P2P.c.

fn_NetSim_P2P_WritePacketTrace()

int fn_NetSim_P2P_WritePacketTrace	(	NetSim_PACKET *	pstruPacket,
		char **	ppszTrace
	)

This function will return the string to write packet trace.

Definition at line 264 of file P2P.c.

getModulationFromString()

PHY_MODULATION getModulationFromString

(

char *

val

)

Definition at line 74 of file P2P.c.

Here is the caller graph for this function:

p2p_CalculateReceivedPower()

static int p2p_CalculateReceivedPower ( NETSIM_ID  tx, NETSIM_ID  txi, NETSIM_ID  rx, NETSIM_ID  rxi  )

static

Definition at line 314 of file P2P.c.

Here is the caller graph for this function:

p2p_gettxinfo()

static void p2p_gettxinfo ( NETSIM_ID  nTxId, NETSIM_ID  nTxInterface, NETSIM_ID  nRxId, NETSIM_ID  nRxInterface, PTX_INFO  Txinfo  )

static

Definition at line 269 of file P2P.c.

Here is the caller graph for this function:

P2P_MacIn_Handler()

int P2P_MacIn_Handler

(

)

Definition at line 92 of file P2P_Mac.c.

Here is the call graph for this function:

Here is the caller graph for this function:

P2P_MacOut_Handler()

int P2P_MacOut_Handler

(

)

Definition at line 28 of file P2P_Mac.c.

Here is the call graph for this function:

Here is the caller graph for this function:

P2P_PhyIn_Handler()

int P2P_PhyIn_Handler

(

)

Definition at line 317 of file P2P_Phy.c.

Here is the call graph for this function:

Here is the caller graph for this function:

P2P_PhyOut_Handler()

int P2P_PhyOut_Handler

(

)

Definition at line 243 of file P2P_Phy.c.

Here is the call graph for this function:

Here is the caller graph for this function:
