IEEE1609.h File Reference

#include "IEEE1609_Enum.h"
#include "IEEE1609_Interface.h"

Include dependency graph for IEEE1609.h:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Macros
#define	_NETSIM_IEEE1609_H_
#define	IEEE1609_SECONDARY_PROTOCOL_DEFAULT   _strdup("IEEE802.11")
#define	IEEE1609_STANDARD_CHANNEL_SCH_DEFAULT   _strdup("36_5180")
#define	IEEE1609_STANDARD_CHANNEL_CCH_DEFAULT   _strdup("38_5190")
#define	IEEE1609_SCH_TIME_DEFAULT   10000
#define	IEEE1609_CCH_TIME_DEFAULT   10000
#define	IEEE1609_GUARD_TIME_DEFAULT   10

Functions
bool	isIEEE1609_Configure (NETSIM_ID nDeviceId, NETSIM_ID nInterfaceId)
void	fn_NetSim_WSNP_SendWSMPacket ()
int	fn_NetSim_WSNP_ReceiveWSMPacket ()
void	fn_NetSim_IEEE1609_ChannelSwitch_Start ()
void	fn_NetSim_IEEE1609_ChannelSwitch_End ()
void	Init_Channel_Switching (NETSIM_ID ndeviceId, NETSIM_ID nInterfaceId)
void	restart_transmission ()

Macro Definition Documentation

_NETSIM_IEEE1609_H_

#define _NETSIM_IEEE1609_H_

Definition at line 16 of file IEEE1609.h.

IEEE1609_CCH_TIME_DEFAULT

#define IEEE1609_CCH_TIME_DEFAULT   10000

Definition at line 36 of file IEEE1609.h.

IEEE1609_GUARD_TIME_DEFAULT

#define IEEE1609_GUARD_TIME_DEFAULT   10

Definition at line 37 of file IEEE1609.h.

IEEE1609_SCH_TIME_DEFAULT

#define IEEE1609_SCH_TIME_DEFAULT   10000

Definition at line 35 of file IEEE1609.h.

IEEE1609_SECONDARY_PROTOCOL_DEFAULT

#define IEEE1609_SECONDARY_PROTOCOL_DEFAULT   _strdup("IEEE802.11")

Definition at line 32 of file IEEE1609.h.

IEEE1609_STANDARD_CHANNEL_CCH_DEFAULT

#define IEEE1609_STANDARD_CHANNEL_CCH_DEFAULT   _strdup("38_5190")

Definition at line 34 of file IEEE1609.h.

IEEE1609_STANDARD_CHANNEL_SCH_DEFAULT

#define IEEE1609_STANDARD_CHANNEL_SCH_DEFAULT   _strdup("36_5180")

Definition at line 33 of file IEEE1609.h.

Function Documentation

fn_NetSim_IEEE1609_ChannelSwitch_End()

void fn_NetSim_IEEE1609_ChannelSwitch_End

(

)

Definition at line 30 of file Channel.c.

Here is the call graph for this function:

Here is the caller graph for this function:

fn_NetSim_IEEE1609_ChannelSwitch_Start()

void fn_NetSim_IEEE1609_ChannelSwitch_Start

(

)

Definition at line 62 of file Channel.c.

Here is the caller graph for this function:

fn_NetSim_WSNP_ReceiveWSMPacket()

int fn_NetSim_WSNP_ReceiveWSMPacket

(

)

Definition at line 116 of file WSMP.c.

Here is the caller graph for this function:

fn_NetSim_WSNP_SendWSMPacket()

void fn_NetSim_WSNP_SendWSMPacket

(

)

Definition at line 36 of file WSMP.c.

Here is the call graph for this function:

Here is the caller graph for this function:

Init_Channel_Switching()

void Init_Channel_Switching	(	NETSIM_ID	ndeviceId,
		NETSIM_ID	nInterfaceId
	)

Definition at line 17 of file Channel.c.

isIEEE1609_Configure()

bool isIEEE1609_Configure	(	NETSIM_ID	nDeviceId,
		NETSIM_ID	nInterfaceId
	)

restart_transmission()

void restart_transmission

(

)

Definition at line 161 of file IEEE1609.c.

Here is the caller graph for this function:
