#include <RIP.h>

Collaboration diagram for stru_RIPEntry:

Data Fields
unsigned int	nAddress_family_identifier:16
	This is used to identify the Address family of the IP address. More...

short int	RouteTag

NETSIM_IPAddress	szIPv4_address
	Destination IPv4 address More...

NETSIM_IPAddress	szSubnet_Mask
	Destination Subnet Mask More...

NETSIM_IPAddress	szNext_Hop

unsigned int	nMetric
	Cost to reach the destination. More...

struct stru_RIPEntry *	pstru_RIP_NextEntry

Detailed Description

 The format for the 20-octet route entry (RTE) for
 RIP-2 is:

 0                   1                   2                   3 3
 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1
+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+
| Address Family Identifier (2) |        Route Tag (2)          |
+-------------------------------+-------------------------------+
|                         IP Address (4)                        |
+---------------------------------------------------------------+
|                         Subnet Mask (4)                       |
+---------------------------------------------------------------+
|                         Next Hop (4)                          |
+---------------------------------------------------------------+
|                         Metric (4)                            |
+---------------------------------------------------------------+

Definition at line 128 of file RIP.h.

Field Documentation

◆ nAddress_family_identifier

unsigned int stru_RIPEntry::nAddress_family_identifier

This is used to identify the Address family of the IP address.

Definition at line 130 of file RIP.h.

◆ nMetric

unsigned int stru_RIPEntry::nMetric

Cost to reach the destination.

Definition at line 136 of file RIP.h.

◆ pstru_RIP_NextEntry

struct stru_RIPEntry* stru_RIPEntry::pstru_RIP_NextEntry

Definition at line 137 of file RIP.h.

◆ RouteTag

short int stru_RIPEntry::RouteTag

Definition at line 131 of file RIP.h.

◆ szIPv4_address

NETSIM_IPAddress stru_RIPEntry::szIPv4_address

Destination IPv4 address

Definition at line 132 of file RIP.h.

◆ szNext_Hop

NETSIM_IPAddress stru_RIPEntry::szNext_Hop

The immediate next hop IP address to which packets to the destination. specified by this route entry should be forwarded

Definition at line 134 of file RIP.h.

◆ szSubnet_Mask

NETSIM_IPAddress stru_RIPEntry::szSubnet_Mask

Destination Subnet Mask

Definition at line 133 of file RIP.h.

The documentation for this struct was generated from the following file:

RIP.h
